Ceramic Calibration Sphere (D = 15.875 mm)
Ceramic Calibration Sphere (D = 15.875 mm)
ID: G39002200
Price:  €462.00
Quick Overview:

Calibration sphere (Ø15.875 mm) made out of ceramic with M8 thread for use of CMMs.
  • Sphere Material:  Ceramic
  • Sphere Diameter:  15.875mm
  • External Thread:  M8
Delivery > 25 days
Ceramic Calibration Sphere Kit (D = 25 mm, H = 200 mm)
Ceramic Calibration Sphere Kit (D = 25 mm, H = 200 mm)
ID: G39031501
Price:  €1,270.00
Quick Overview:

Calibration sphere set, included a certified calibration sphere (Ø25 mm) made out of ceramic and a support to position the sphere in different angles. Total height 200 mm and M8 machine fixing for use with CMMs.
  • Sphere Material:  Ceramic
  • Sphere Diameter:  25mm
  • External Thread:  M8
Delivery > 25 days
Ceramic Calibration Sphere Kit (D = 25 mm, H = 170 mm)
Ceramic Calibration Sphere Kit (D = 25 mm, H = 170 mm)
ID: G39032100
Price:  €792.00
Quick Overview:

Calibration sphere set, included a certified calibration sphere (Ø25 mm) made out of ceramic and an extension (120 mm). The set has a total height of 170 mm and M8 machine fixing for use with CMMs.
  • Sphere Material:  Ceramic
  • Sphere Diameter:  25mm
  • External Thread:  M8
Delivery > 25 days
Ceramic Calibration Sphere Kit (D = 15 mm, H = 200 mm)
Ceramic Calibration Sphere Kit (D = 15 mm, H = 200 mm)
ID: G39031401
Price:  €770.00
Quick Overview:

Calibration sphere set, included a certified calibration sphere (Ø15 mm) made out of ceramic and a support to position the sphere in different angles. Total height 200 mm and M8 machine fixing for use with CMMs.
  • Sphere Material:  Ceramic
  • Sphere Diameter:  15mm
  • External Thread:  M8
Delivery > 25 days
Certified Length Bar (short)
Certified Length Bar (short)
ID: 32377
Price:  €452.00
Quick Overview:  Small-sized certified length bar. Recommended for use with Absolute arm models of size 1.2 m.
  • Recommended Arm Size:  1.2m
  • Certification:  DIN ISO-17025
Delivery time 10-15 days
Absolute Arm Dust Cover (1.2 m)
Absolute Arm Dust Cover (1.2 m)
ID: H00006817
Price:  €77.00
Quick Overview:  Hexagon-branded protective cover for Absolute Arm size 1.2 m.
  • Compatibility:  Absolute Arm RA7, Absolute Arm RA8
  • Recommended Arm Size:  1.2m
Delivery time 10-15 days
Tube Holder (Ø 0-20 mm)
Tube Holder (Ø 0-20 mm)
ID: EBD-12865
Price:  €1,375.00
Quick Overview:  Fixture for securely holding tubes during measurement. Compatible with tubes up to Ø20 mm.
  • Max. Tube Diameter:  0 - 20mm
Delivery time 10-15 days
Tube Holder (Ø 20-70 mm)
Tube Holder (Ø 20-70 mm)
ID: EBD-12866
Price:  €1,430.00
Quick Overview:  Fixture for securely holding tubes during measurement. Compatible with tubes from Ø20 mm to Ø70 mm.
  • Max. Tube Diameter:  20 - 70mm
Delivery time 10-15 days
Absolute Arm Raiser (500 mm) with Mounting Ring 3.5"
Absolute Arm Raiser (500 mm) with Mounting Ring 3.5"
ID: NCA7-5-52795
Price:  €2,500.00
Quick Overview:

Multi-purpose 500 mm stand, suitable for Absolute Arm tube stations as well as other high-accuracy arm applications. For use with all Absolute Arm models, except Absolute Arm model RA8v3.
  • Recommended Arm Size:  1.5 - 4.5
  • Compatibility:  Absolute Arm RA7, Absolute Arm RA8
Delivery time 10-15 days
Absolute Arm Raiser (250 mm) with Mounting Ring 3.5"
Absolute Arm Raiser (250 mm) with Mounting Ring 3.5"
ID: NCA7-5-52794
Price:  €2,100.00
Quick Overview:

Multi-purpose 250 mm stand, suitable for Absolute Arm tube stations as well as other high-accuracy arm applications. For use with all Absolute Arm models, except Absolute Arm model RA8v3.
  • Recommended Arm Size:  1.5 - 4.5
  • Compatibility:  Absolute Arm RA7, Absolute Arm RA8
Delivery time 10-15 days
Probe with M3-Stylus (R-6-C-85)
Probe with M3-Stylus (R-6-C-85)
ID: 54397-02
Price:  €510.00
Quick Overview:  85 mm carbon probe with mounted ruby ball M3-Stylus Ø6 mm. For use with all Absolute Arm models.
  • Tip Diameter:  6mm
  • Length:  85mm
Delivery time 10-15 days
Probe with M3-Pointer Stylus (A-75)
Probe with M3-Pointer Stylus (A-75)
ID: 54388-06
Price:  €510.00
Quick Overview:  75 mm aluminium probe with mounted M3-Pointer Stylus. For use with all Absolute Arm models.
  • Length:  75mm
Delivery time 10-15 days
Probe with M3-Pointer Stylus (C-85)
Probe with M3-Pointer Stylus (C-85)
ID: 54397-03
Price:  €510.00
Quick Overview:  85 mm carbon probe with mounted M3-Pointer Stylus. For use with all Absolute Arm models.
  • Length:  85mm
Delivery time 10-15 days
Probe with M3-Pointer Stylus (A-100)
Probe with M3-Pointer Stylus (A-100)
ID: 54388-09
Price:  €510.00
Quick Overview:  100 mm aluminium probe with mounted M3-Pointer Stylus. For use with all Absolute Arm models.
  • Length:  100mm
Delivery time 10-15 days
Angle Probe 45DEG with M3-Pointer Stylus (TC-10)
Angle Probe 45DEG with M3-Pointer Stylus (TC-10)
ID: H00033800-01
Price:  €790.00
Quick Overview:  Angled probe (45°) with mounted M3-Pointer Stylus. For use with all Absolute Arm models.
  • Angle:  45°
  • Offset (Y):  38mm
  • Length:  149mm
  • Protection Class:  IP54
Delivery time 10-15 days
Angle Probe 90DEG with M3-Pointer Stylus (TC-L10)
Angle Probe 90DEG with M3-Pointer Stylus (TC-L10)
ID: H00033800-09
Price:  €790.00
Quick Overview:  Angled probe (90°) with mounted M3-Pointer Stylus. For use with all Absolute Arm models.
  • Angle:  90°
  • Offset (Y):  43mm
  • Length:  173mm
  • Protection Class:  IP54
Delivery time 10-15 days
Angle Probe 60DEG with M3-Pointer Stylus (TC-L10)
Angle Probe 60DEG with M3-Pointer Stylus (TC-L10)
ID: H00033800-05
Price:  €790.00
Quick Overview:  Angled probe (60°) with mounted M3-Pointer Stylus. For use with all Absolute Arm models.
  • Angle:  60°
  • Offset (Y):  57mm
  • Length:  149mm
  • Protection Class:  IP54
Delivery time 10-15 days
Angle Probe 60DEG with M3-Stylus (R-6-SS-2.7-L10)
Angle Probe 60DEG with M3-Stylus (R-6-SS-2.7-L10)
ID: H00033800-08
Price:  €790.00
Quick Overview:  Angled probe (60°) with mounted M3-Stylus, tip Ø6 mm. For use with all Absolute Arm models.
  • Angle:  60°
  • Tip Diameter:  6mm
  • Offset (Y):  57mm
  • Length:  149mm
  • Protection Class:  IP54
Delivery time 10-15 days
Angle Probe 60DEG with M3-Stylus (R-3-SS-1.5-L10)
Angle Probe 60DEG with M3-Stylus (R-3-SS-1.5-L10)
ID: H00033800-06
Price:  €790.00
Quick Overview:  Angled probe (60°) with mounted M3-Stylus, tip Ø3 mm. For use with all Absolute Arm models.
  • Angle:  60°
  • Tip Diameter:  3mm
  • Offset (Y):  57mm
  • Length:  149mm
  • Protection Class:  IP54
Delivery time 10-15 days
Angle Probe 60DEG with M3-Stylus (R-4-SS-2.5-L10)
Angle Probe 60DEG with M3-Stylus (R-4-SS-2.5-L10)
ID: H00033800-07
Price:  €790.00
Quick Overview:  Angled probe (60°) with mounted M3-Stylus, tip Ø4 mm. For use with all Absolute Arm models.
  • Angle:  60°
  • Tip Diameter:  4mm
  • Offset (Y):  57mm
  • Length:  149mm
  • Protection Class:  IP54
Delivery time 10-15 days
