M3-Stylus (R-1.5-TC-1-L20) SKU: 03969431

$44.00

Stock goods

Straight stylus with M3 thread, ruby ball Ø1.5 mm, tungsten carbide stem Ø1 mm, length 20 mm. For use on coordinate measuring machines (CMM).

Thread	M3
Tip Material	Ruby
Tip Diameter (D)	1.5 mm
Length (L)	20 mm
Stem Material	Tungsten Carbide

M3-Stylus (R-5-SS-2.5-L21) SKU: 03969305

$32.00

Stock goods

Straight stylus with M3 thread, ruby ball Ø5 mm, stainless steel stem Ø2.5 mm, length 21 mm. For use on coordinate measuring machines (CMM).

Thread	M3
Tip Material	Ruby
Tip Diameter (D)	5 mm
Length (L)	21 mm
Stem Material	Stainless Steel

Magnetic Base with Mounting Ring SKU: NCA7-5-19866

$2,500.00

Stock goods

Standard magentic base and mounting ring set. For use with all Absolute Arm models.

Ring Diameter

108 mm

M2-Stylus (R-4-CF-2-L75) SKU: 03969424

$135.00

Stock goods

Straight stylus with M2 thread, ruby ball Ø4 mm, carbon fiber stem Ø2 mm, length 75 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Ruby
Tip Diameter (D)	4 mm
Length (L)	75 mm
Stem Material	Carbon Fiber

M2-Disc Stylus (SV-18-SS-L7.5) SKU: 03969242

$89.00

Stock goods

Disc stylus with M2 thread, silver steel disc Ø18 mm, length 7.5 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Stainless Steel
Disc Diameter (D)	18 mm
Length (L)	7.5 mm

M2-Stylus Extension (SS-3-L10) SKU: 03969231

$13.00

Stock goods

Stylus extension with M2 thread, stainless steel stem Ø3 mm, length 10 mm

Thread	M2
Diameter Stem (D)	3 mm
Stem Material	Stainless Steel
Length (L)	10 mm

M2-Stylus (R-4-SS-2-L20) SKU: 03969214

$25.00

Stock goods

Straight stylus with M2 thread, ruby ball Ø4 mm, stainless steel stem Ø2 mm, length 20 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Ruby
Tip Diameter (D)	4 mm
Length (L)	20 mm
Stem Material	Stainless Steel

M2-Star Stylus 4-way (R-0.5-TC-0.3-SP20) SKU: 03969210

$264.00

Stock goods

Star stylus with M2 thread, ruby ball Ø0.5 mm, tungsten carbide stem Ø0.3 mm, span 20 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Ruby
Tip Diameter (D)	0.5 mm
Stem Material	Tungsten Carbide

M2-Spherical Cylinder Stylus (TC/TC-2-L40) SKU: 03969280

$87.00

Stock goods

Spherical cylinder stylus with M2 thread, tungsten carbide cylinder Ø2 mm, length 40 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Tungsten Carbide
Tip Diameter (D)	2 mm
Length (L)	40 mm
Stem Material	Tungsten Carbide

M3-Hollow Ball Stylus (CE-30-L17) SKU: 03969330

$343.00

Stock goods

Stylus with M3 thread and hollow ceramic ball Ø30 mm, length 17 mm. For use on coordinate measuring machines (CMM).

Thread	M3
Tip Material	Ceramic
Tip Diameter (D)	30 mm
Length (L)	17 mm

M2-Stylus Extension (SS-3-L30) SKU: 03969233

$17.00

Stock goods

Stylus extension with M2 thread, stainless steel stem Ø3 mm, length 30 mm

Thread	M2
Diameter Stem (D)	3 mm
Stem Material	Stainless Steel
Length (L)	30 mm

HP-S-X1C/H Stylus Module (1x D2) SKU: M00-694-275-000

$491.00

Stock goods

Aluminium stylus module for scanning probes HP-S-X1C/H (1x D2)

Related Probe	HP-S-X1C HP-S-X1H
Female Thread (C)	D2
Material	Aluminium
Length (L)	9.3 mm

M2-Stylus (R-1-TC-0.7-L20) SKU: 03969221

$49.00

Stock goods

Straight stylus with M2 thread, ruby ball Ø1 mm, tungsten carbide stem Ø0.7 mm, length 20 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Ruby
Tip Diameter (D)	1 mm
Length (L)	20 mm
Stem Material	Tungsten Carbide

M5-Stylus (R-1.5-TC-1-L40) SKU: M02-J01-100-001

$131.00

Stock goods

Straight stylus with M5 thread, ruby ball Ø1.5 mm, tungsten carbide stem Ø1 mm, length 40 mm. For use on coordinate measuring machines (CMM).

Thread	M5
Tip Material	Ruby
Tip Diameter (D)	1.5 mm
Length (L)	40 mm
Stem Material	Tungsten Carbide

M4-Stylus (R-6-CE-4.5-L100) SKU: 03969427

$109.00

Stock goods

Straight stylus with M4 thread, ruby ball Ø6 mm, ceramic stem Ø4.5 mm, length 100 mm. For use on coordinate measuring machines (CMM).

Thread	M4
Tip Material	Ruby
Tip Diameter (D)	6 mm
Length (L)	100 mm
Stem Material	Ceramic

HP-S-X1C/H Stylus Module with Starholder (5x M3) SKU: M00-694-270-000

$687.00

Stock goods

Aluminium stylus module with Dispal® star holder for scanning probes HP-S-X1C/H (5x M3)

Related Probe	HP-S-X1C HP-S-X1H
Female Thread (C)	M3
Female Thread (C1)	4 x M3
Material	Aluminium / Dispal®
Length (L)	36.5 mm

Certified Length Bar (medium) SKU: 32378

$650.00

Stock goods

Medium-sized certified length bar. Recommended for use with Absolute Arm models of size 2.0 to 2.5 m.

Recommended Arm Size	2.0 - 2.5 m
Certification	DIN ISO-17025

M2-Stylus (R-3-SS-1.5-L20) SKU: 03969213

$25.00

Stock goods

Straight stylus with M2 thread, ruby ball Ø3 mm, stainless steel stem Ø1.5 mm, length 20 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Ruby
Tip Diameter (D)	3 mm
Length (L)	20 mm
Stem Material	Stainless Steel

Angle Probe 90DEG with M3-Pointer Stylus (TC-L10) SKU: 54280-09

$975.00

Stock goods

Angled probe (90°) with mounted M3-Pointer Stylus. For use with all Absolute Arm models.

Angle	90 °
Offset (Y)	43 mm
Length	173 mm

M2-Stylus (R-2.5-SS-1.4-L20) SKU: 03969226

$25.00

Stock goods

Straight stylus with M2 thread, ruby ball Ø2.5 mm, stainless steel stem Ø1.4 mm, length 20 mm. For use on coordinate measuring machines (CMM).

Thread	M2
Tip Material	Ruby
Tip Diameter (D)	2.5 mm
Length (L)	20 mm
Stem Material	Stainless Steel
